System

CPU

Intel® Elkhart Lake Celeron J6412 Quad-core 2.0GHz , TDP 10W

L2 Cache

1.5MB

System Chipset

Integrated with Intel® SoC

Memory

DDR4L 3200MHz 4GB, MAX 32GB

Harddisk

1 x M.2 120G SSD ( 250G / 500G / 2TB SSD)

Graphics

Intel® UHD Graphics for 10th Gen Intel® Processors

Network

Intel® 225-V GbE LAN

Audio

Realtek ACL897 Audio controller

TPM

TPM 2.0

Operation System

Windows 10 / 11， Linux, Ubuntu

I/O

VIDEO

1 x H-DMI ( Optional )

LAN

2 x M12 Waterproof Giga LAN RJ45 Connector

USB

2 x M12 Waterproof Connector For USB2.0

COM

1 x M12 Waterproof Connector For COM

Wireless Network

WiFi + Bluetooth ( Optional )

Other I/O Interface

1 x Power Switch

Display

LCD Size

12.1" ( 4:3 )

Resolution

800x600 / 1024x768 (Optional)

Brightness (cd/m²)

500 cd/m2

Contrast Ratio

1200:1

Backlight MTBF

50000 hrs

Viewing Angle

88 / 88 / 88 / 88 (CR≥10) ( L / R / U / D )

Touch screen

Touch Type

5 wire Resistive touch

Surface Hardness

≥3H

Power

Power Input

1 x M12 Waterproof Connector For 9V~36V DC

Power Protection

OVP (Over Voltage Protection) / OCP (Over Current Protection) / RPP（Reverse Polarity  Protection）

Power Consumption

≦35W

Physical

Material

Aluminum Alloy Shell

Mounting

Stand / Wall / VESA / Yoke

Dimension (W x H x D）

311 x 241 x 42 mm

Packing Size

450 x 170 x 350 mm

Weight (Net)

3.5 KG

Environment

Operating Temperature

-20~70°C  ( -4~158°F )

Storage Temperature

-30~80°C (-22~176°F)

Relative Humidity

5%~95%@40°C, non-condensing

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

IP67 / IP69K

EMC

CE, FCC，Class A，ROHS
