System

CPU

12th Gen Intel® Core™ i3-1215U 1.2GHz

12th Gen Intel® Core™ i5-1235U 1.3GHz

12th Gen Intel® Core™ i7-1255U 1.7GHz

TDP

15W

15W

15W

L2 Cache

10MB

12MB

12MB

Graphics

Intel® UHD Graphics

Intel® Iris® Xe Graphics

Intel® Iris® Xe Graphics

System Chipset

Integrated with Intel® SoC

Memory

DDR5 4800 MHz, Dual Channel SODIMM x 2, up to 64GB

Harddisk

1 x M.2 120G SSD ( 250G / 500G / 2TB SSD) / 1 x 2.5" SATA

Network

Intel® 226-V / I219-LM GbE LAN

Audio

Realtek ALC897 Audio controller

TPM

TPM 2.0

Watchdog Timer

Software Programmable Supports 1~255 sec. System Reset

Operation System

Windows 10 / 11， Linux, Ubuntu

I/O

VIDEO

1 x H-DMI

LAN

2 x M12 Waterproof Giga LAN RJ45 Connector

USB

2 x M12 Waterproof Connector For USB2.0

COM

1 x M12 Waterproof Connector For COM

Wireless Network

1 x WiFi / Bluetooth , Optional ( 4G / 5G )

Other I/O Interface

1 x Power Switch

Expansion

M.2

1*M.2 ( Key-E, 2230, PCIe+USB, Wifi+BT )

1*M.2 ( Key-B, 3042/3052, PCIe/ USB 3.0+USB2.0, 4G/5G )

1*M.2 ( Key-M, 2280, NVMe / SATA, SSD )

SIM Socket

1x SIM Socket

Power

Power Input

1 x M12 Waterproof Connector For 9V~36V DC

Power Mode

Support AT, ATX Mode

Power Protection

OVP (Over Voltage Protection) / OCP (Over Current Protection) / RPP（Reverse Polarity  Protection）

Power Consumption

≦45W

Physical

Material

Aluminum Alloy Shell

Color

Grey / Silver / Black ( optional )

Mounting

220 x 250 x 55 mm

Packing Size

360 x 180 x 320 mm

Weight (Net)

2.5 KG

Environment

Operating Temperature

-30~70°C  ( -22~158°F )

Storage Temperature

-40~85°C (-40~185°F)

Relative Humidity

10% to 95% (non-condensing)

Vibration Protection

1.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis

IP Level

IP67 / IP69K

EMC

CE, FCC，Class A，ROHS

ORDERING INFORMATION

AVAILABLE MODELS

DESCRIPTION

EFIC-60003A

12th Gen Intel Core i3-1215U 1.2GHz / 1 x HDMI / 2 x LAN / 2 x USB2.0 / 1 x COM / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

EFIC-60005A

12th Gen Intel Core i5-1235U 1.3GHz / 1 x HDMI / 2 x LAN / 2 x USB2.0 / 1 x COM / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

EFIC-60007A

12th Gen Intel Core i7-1255U 1.7GHz / 1 x HDMI / 2 x LAN / 2 x USB2.0 / 1x COM / TPM2.0 / DC 9V~36V (OVP / OCP / RPP)

CONFIGURATION

DESCRIPTION

Memory

RAM：DDRR 4800MHz SO-DIMM x 2.64GB

Harddisk

M.2 SSD：(120G/250G/500G/2TB) 1 x 2.5" SATA

WiFi

Wi-Fi Bluetooth Combo Module, with antenna

4G/5G

Full Netcom 4G/5G/LTE module, with antenna

PACKING LIST

1 x Standard product

1 x 60W PSU (Power Supply)

1 x Fixed support

2 x M12 Waterproof USB Cable 2M

1 x M12 Waterproof COM Cable 2M

2 x M12 Waterproof LAN Cable 2M

1 x Waterproof HDMI Cable 2M

1 x CD-ROM
